1 12

Specialized

Turbo Levo 4 Comp

Turbo Levo 4 Comp

95224-5603

$13,900.00
$0.00 $13,900.00
Sale Contact Us for Availability
Tax included. Shipping calculated at checkout.
Colour
Size
View Size Guide

Find in-store

Loading locations...

Product enquiry

Thank you for submitting your form!

We appreciate your interest and will review your information as soon as possible.

Our team is dedicated to providing excellent customer service, and we will do our best to respond promptly.

View full details

Product Details

The Specialized Science Club Introduces the Levo 4, an electric mountain bike so advanced it transforms you into a cycling cyborg. Together you're SuperNatural, fortified with super power, traction, control, and range to conquer any off-road terrain. Levo 4, Where Super Meets Natural. Use - Full Power E-MTB Trail

E-System - Specialized 3.1 Motor w/ 810 Watts & 105 Nm, 840 Wh Battery, up to 5 hour range

Frame - FACT 11m Carbon, Geo Adj & SWAT Storage

Suspension - Front: 160mm FOX 36 Rhythm GRIP, Rear: 150mm GENIE - FOX FLOAT X Performance

Drivetrain - SRAM S1000 Eagle T-Type AXS

Wheels - Specialized Alloy / Bear Pawls hubs







Technical Specifications

Frameset

Frame

All new Levo 4 frame, FACT 11m carbon chassis and rear-end, 12x148mm dropouts, sealed cartridge bearing pivots, SRAM UDH compatible, w/ SWAT storage, 150mm of travel, side entry battery, fork travel up to 180mm

Seat Binder

Alloy, 38.6mm

SWAT

SWAT internal downtube storage

Suspension

Fork

FOX FLOAT 36 Rhythm, GRIP damper, two position Sweep adjustment, 15x110mm axle, 44mm offset, 160mm of travel

Rear Shock

FOX FLOAT X Performance with Specialized GENIE Shock Tech, Ride Dynamics Trail Tune, 2-position lever, LSR adjustment

Cockpit

Seat Post

Xfusion Manic, infinite adjustable, two bolt head, Remote SLR LE lever, 34.9, S2: 125mm, S3: 170mm, S4-S6: 190mm

Saddle

Bridge Comp, Hollow Cr-mo rails

Stem

Alloy Trail Stem, 35mm bar bore

Grips

Specialized Trail Grips

Handlebars

Alloy handlebars, 35mm diameter, 8 degree back sweep, 6 degree up sweep, S2: 30mm rise, 780mm width, S3-S5: 40mm rise 800mm width

Brakes

Front Brake

SRAM Maven Bronze, 4-piston caliper, hydraulic disc, 220mm Rotor

Rear Brake

SRAM Maven Bronze, 4-piston caliper, hydraulic disc, 200mm Rotor

Drivetrain

Shift Levers

SRAM AXS POD Controller

SRAM S1000 Eagle Transmission, Wired SRAM AXS battery (powers AXS rear derailleur with integrated hot shoe directly off the Levo 4 main battery).

SRAM S1000 Eagle Transmission, Wired SRAM AXS battery (powers AXS rear derailleur with integrated hot shoe directly off the Levo 4 main battery).

Cassette

SRAM 12-speed,10-52t

Crankset

SRAM S1000 Crankset, ISIS interface, Integrated Guard, 55mm Chainline, 155mm

Chain

SRAM GX Eagle Transmission Flattop Chain

Chain Ring

SRAM T-type ring, 34T, 104 BCD, steel

E-Bike

Battery

840Wh battery

Charger

Specialized 4amp charger

Motor

Specialized 3.1 Motor, 105Nm torque, 810W power

UI Remote

All New MasterMind T3 Display System, 2.2" high resolution color screen, fully customizeable with Specialized app

Wheels & Tyres

Front Hub

Sealed cartridge bearings, 6-bolt, 15x110mm thru-axle, 32h

Rear hub

Alloy, sealed cartridge bearings, 12x148mm thru-axle, 32h

Butcher, GRID GRAVITY casing, GRIPTON® T9 compound, 2Bliss Ready, 29x2.3"

Butcher, GRID GRAVITY casing, GRIPTON® T9 compound, 2Bliss Ready, 29x2.3"

Butcher, GRID GRAVITY casing, GRIPTON® T9 compound, 2Bliss Ready, 27.5x2.3"

Butcher, GRID GRAVITY casing, GRIPTON® T9 compound, 2Bliss Ready, 27.5x2.3"

Spokes

DT Swiss Industry

Tubes

Standard, Presta valve

Accessories
