Specialized
Crux Comp Carbon
Crux Comp Carbon
SKU:91422-5154
Find in-store
files/91422-51_CRUX-COMP-SMK-BLK-CLGRY_HERO.webp
08:26 PM
Product Enquiry
Thank you for submitting your form!
We appreciate your interest and will review your information as soon as possible.
Our team is dedicated to providing excellent customer service, and we will do our best to respond promptly.
Crux Size Guide
Product Details
📸 View our gallery of studio photographs here in the 'Satin Smoke/Black/Cool Grey' colour scheme. That too, of the Crux in the wild!
The Crux is the lightest gravel bike in the world, with the exceptional capability of massive tyre clearance and performance gravel geometry. It’s the ultimate expression of gravel performance.
The Crux Comp Carbon comes spec'd with a reliable and smooth-shifting SRAM Rival 1 hydraulic disc groupset, tough DT Swiss G540 Disc wheels and tubeless ready, 700x38mm Pathfinder Pro tyres that smooth out the rutted corrugations and dust of Molesworth or Colville alike.
- The Comp Carbon uses the 825g, 10r FACT carbon fibre frame. Taken are the revolutionary breakthroughs that made Aethos the lightest bike ever and applied them to the Crux. The result? A gravel bike that climbs like a dream, floats over jagged terrain, and weighs less than a full bottle in your cage. Watch here, the engineers tell of how the Crux came to be.
- Tyre clearance for up to 47mm on 700c wheels and/2.1” on 650B wheels respectively. More clearance means more capability. With Diverge-level tyre clearance, Crux takes you anywhere you can imagine, at full gas.
- Responsive: Nimble, supple, and reactive. Responsive at the pedals. Supple in the saddle. With performance gravel geometry and race-influenced fit inspired by Crux's iconic history in ‘cross.
Specifications:
|
Frame |
Crux 10r FACT carbon fibre, Rider First Engineered, Threaded BB, 12x142mm thru-axle, flat-mount disc |
|
Fork |
S-Works FACT carbon fibre, 12x100mm thru-axle, flat-mount disc |
|
Handlebars |
Specialized Adventure Gear, 118.9mm drop x 70mm reach x 12º flare |
|
Stem |
Specialized, 3D-forged alloy, 4-bolt, 7-degree rise |
|
Tape |
Supacaz Super Sticky Kush |
|
Saddle |
Body Geometry Power Sport, steel rails |
|
Front Brake |
SRAM Rival, hydraulic disc |
|
Rear Brake |
SRAM Rival, hydraulic disc |
|
Shift Levers |
SRAM Rival 1, hydraulic |
|
Rear Derailleur |
SRAM Rival 1, long cage |
|
Cassette |
SunRace, 11-speed, 11-42t |
|
Crankset |
SRAM Rival 1x |
|
Chainrings |
40T |
|
Bottom Bracket |
SRAM GXP |
|
Chain |
KMC X11 Extra Lightweight, 11-speed |
|
Front Wheel |
DT Swiss G540 Disc |
|
Rear Wheel |
DT Swiss G540 Disc |
|
Front Tyre |
Pathfinder Pro Tubeless Ready, Tan Sidewall, 700x38mm |
|
Rear Tyre |
Pathfinder Pro Tubeless Ready, Tan Sidewall, 700x38mm |
|
Inner Tubes |
Presta valve, 48mm |
|
Seat Post |
Roval Terra Carbon Seat Post, 20mm Offset |
|
Seat Post Collar |
Specialized Alloy, 30mm |
|
Test Pedals |
Not included on performance Specialized bikes such as this for environmental reasons. Pedals are an additional purchase, based on preference and riding style. |
Geometry & Sizing:
|
49 |
52 |
54 |
56 |
58 |
61 |
|
|
BB Drop |
74 |
74 |
72 |
72 |
72 |
72 |
|
BB Height |
284 |
284 |
286 |
286 |
286 |
286 |
|
Bike Standover Height |
749 |
772 |
794 |
816 |
841 |
866 |
|
Chainstay Length |
425 |
425 |
425 |
425 |
425 |
425 |
|
Crank Length |
170 |
170 |
172.5 |
172.5 |
175 |
175 |
|
Fork Length, Full |
401 |
401 |
401 |
401 |
401 |
401 |
|
Fork Rake/Offset |
50 |
50 |
50 |
50 |
50 |
50 |
|
Front Center |
594 |
600 |
608 |
618 |
630 |
644 |
|
Handlebar Width |
380 |
400 |
420 |
420 |
440 |
440 |
|
Head Tube Angle |
70.5° |
71.25° |
71.5° |
72° |
72.25° |
72.5° |
|
Head Tube Length |
100 |
115 |
130 |
147 |
167 |
190 |
|
Reach |
375 |
382 |
388 |
397 |
405 |
415 |
|
Saddle Width |
155 |
155 |
143 |
143 |
143 |
143 |
|
Seat Tube Angle |
75.5° |
74° |
74° |
73.5° |
73.5° |
73.5° |
|
Seat Tube Length |
466 |
496 |
521 |
546 |
576 |
606 |
|
Seatpost Length |
330 |
330 |
330 |
380 |
380 |
380 |
|
Stack |
530 |
547 |
560 |
578 |
598 |
621 |
|
Stem Length |
70 |
80 |
90 |
100 |
110 |
110 |
|
Top Tube Length, Horizontal |
512 |
539 |
549 |
568 |
582 |
599 |
|
Trail |
74 |
69 |
67 |
64 |
62 |
60 |
|
Wheelbase |
1008 |
1014 |
1023 |
1033 |
1045 |
1059 |
*Barring angle values marked by their degree symbol (°), all chart measurements above are listed in millimetres (mm).
Detailed below are the 2022 Crux Comp's sizes, with their respective rider's height ranges to which they suit:
49cm - 155cm to 158cm (5'1" to 5'4")
52cm - 163cm to 168cm (5'4" to 5'6")
54cm - 168cm to 175cm (5'6" to 5'9")
56cm - 175cm to 183cm (5'9" to 6'0")
58cm - 183cm to 191cm (6'0" to 6'3")
61cm - 191cm to 198cm (6'3" to 6'6")
